LARGUS SPEC S COILOVER KIT FOR TOYOTA COROLLA TOURING ZWE214W 4WD 01011209113-QQ-9
| Brand | LARGUS |
| Series Name | SPEC S COILOVER KIT |
| Product Number | 01011209113-QQ-9 |
| Compatible Car | TOYOTA COROLLA TOURING ZWE214W 4WD |
| Product Description | Product: Full-length adjustable suspension kit Type: SpecS Manufacturer: TOYOTA Model: Corolla Touring Vehicle model: ZWE214W Year: 2019/10~ Drive system: 4WD Frequency: 6kg Rear: 4.5kg Free length: 200mm Free length: 225mm Front upper mount: Fixed reinforced rubber Rear upper mount: Mountless Front damping position: Fixed dial (top of upper mount) Rear damping position: Disc type (inside wheelhouse) Front height adjustment range: 598mm - 670mm Rear height adjustment range: 610mm - 664mm Lowering amount: -69mm~+3mm Down amount R: -58mm~-4mm |
| Remarks | To adjust the front damping force, you will need to drill holes in the steel panel above the upper mount, or disassemble or remove the coilovers. *The vehicle height setting range, lowering amount, and installation images are reference values based on the development vehicle. There may be discrepancies due to individual vehicle differences and assembly conditions. *For vehicles with adaptive shock absorbers (electronically controlled dampers, etc.), a warning light will come on, so a separate canceller or other countermeasure will be required. *The specifications and accessories of this product are subject to change without notice for improvement purposes. CAN ONLY BE SHIPPED WITH UPS OR FEDEX |
| Notes | Images are for illustration purpose only. Actual product may vary. |
| Brand | LARGUS |
| Series Name | SPEC S COILOVER KIT |
| Product Number | 01011209113-QQ-9 |
| Compatible Car | TOYOTA COROLLA TOURING ZWE214W 4WD |
| Product Description | Product: Full-length adjustable suspension kit Type: SpecS Manufacturer: TOYOTA Model: Corolla Touring Vehicle model: ZWE214W Year: 2019/10~ Drive system: 4WD Frequency: 6kg Rear: 4.5kg Free length: 200mm Free length: 225mm Front upper mount: Fixed reinforced rubber Rear upper mount: Mountless Front damping position: Fixed dial (top of upper mount) Rear damping position: Disc type (inside wheelhouse) Front height adjustment range: 598mm - 670mm Rear height adjustment range: 610mm - 664mm Lowering amount: -69mm~+3mm Down amount R: -58mm~-4mm |
| Remarks | To adjust the front damping force, you will need to drill holes in the steel panel above the upper mount, or disassemble or remove the coilovers. *The vehicle height setting range, lowering amount, and installation images are reference values based on the development vehicle. There may be discrepancies due to individual vehicle differences and assembly conditions. *For vehicles with adaptive shock absorbers (electronically controlled dampers, etc.), a warning light will come on, so a separate canceller or other countermeasure will be required. *The specifications and accessories of this product are subject to change without notice for improvement purposes. CAN ONLY BE SHIPPED WITH UPS OR FEDEX |
| Notes | Images are for illustration purpose only. Actual product may vary. |
